WG600S Industrial Variable-Speed Peristaltic Pump
Flow rate: 0.4–13.2 L/min. Up to 2 channels.
- Rotary encoder control for operating speed, reversible direction, start/stop and full-speed mode.
- LF-LED-OS software digitally displays speed and operating status.
- High-torque, maintenance-free brushless motor.
- Easy-to-clean 304 stainless-steel housing resists corrosion caused by organic solvents.
- Timed-operation function for convenient dispensing.
- Conformal-coated circuit board protects against dust and moisture.
Shared specifications and options
Compatible Pump Heads, Tubing and Flow Rate Parameters
| Pump Head | YZ35 |
|---|---|
| Ch | 1, 2 |
| Tubing | 73# 82# |
| Flow Rate (L/min) per channel | 0.4～13.2 |
Specifications
| Parameter | Value |
|---|---|
| Flow Rate Range | 0.4～13.2L/min |
| Speed Range | 30～600rpm |
| Speed Resolution | 1rpm |
| accuracy of Speed | <±3% |
| External Control | level of External Control 5V,12V (standard), 24V (optional), External Control analógico 0-5V (standard), 0-10V, 4-20mA (optional) |
| Communication Interface | RS485 communication interface, MODBUS protocol and DB15 external-control interface |
| Power Supply | AC100～240V, 50Hz/60Hz |
| Power Consumption | <300W |
| Operating Environment | temperature 0 ～ 40℃, relative humidity <80% |
| IP Protection Rating | IP31 |
| Dimensions (LxWxH) | 356x232x224mm |
| Controller Weight | 11 kg |
Compatible Pump Heads, Tubing and Flow Rate Parameters
| Parameter | Value |
|---|---|
| Pump Head | YZ35 |
| Ch | 1, 2 |
| Tubing | 73# 82# |
| Flow Rate (L/min) per channel | 0.4～13.2 |
